OptiGun GA03 Automatic powder gun spare parts

Place of Origin: Zhejiang,China (Mainland)
brand: colo for aftermarket
Delivery way: TNT, FEDX, DHL
Delivery time: according the quantity
Payment: Paypal, western union,T/T
min order amount: 1pcs

inquiry

skype basketAdd to Basket  Edit

Share |

Product Description

Payment & Shipping Terms Supply Capacity
Payment Terms:WUProduction Capacity:1000 sets/month
Means of Transport:AirPacking:bag ,cartson
Delivery Date:1-2days

OptiGun GA03 Automatic powder gun spare parts

Ordering spare parts

When ordering spare parts for powder coating equipment, please indicate

the following specifications:

- Type of your powder coating equipment

- Order number, quantity and description of each spare part

1 Powder gun body OptiGun GA03 ?complete, polarity negative 1008 726

Powder gun body OptiGun GA03 ?complete, polarity positive 1008 727

2 Threaded sleeve ?see "Nozzle combinations" spare parts list

3 Flat jet nozzle ?complete, see "Nozzle combinations" spare parts list

4 Gun cable ?complete, 20 m, see also spare parts list "Gun cable" 1008 663

5 Cylinder screw ?M8x50 mm 235 113

6 Washer ??8.4/20x2 mm 215 880

7 Cable tie with Velcro closure (8x) (not shown) 303 070

8 Quick release connection - NW5, ?6 mm, for pos. 11 (not shown) 200 840

9 Cleaning brush ??12 mm (not shown) 389 765

10 Powder hose ??16/11 mm (not shown) 105 139*

11 Electrode rinsing air hose ??6/4 mm (not shown) 103 144


OptiGun GA03 – gun body

1 OptiGun GA03 shaft – complete, negative polarity (see spare parts list "Shaft")

Powder tube – complete (incl. pos. 2-5) 1008 644#

2 Powder tube 1008 641#

3 O-ring – Ø 12x1 mm, FPM75 1006 324#

4 Hose holder 1008 642#

5 Clamp ring 1008 643

6 Gun fixture 1008 711

7 Ground plate 1011 457

8 SuperCorona connection 1009 764

9 Screw – M5x6 mm 263 907


OptiGun GA03 ?shaft

Shaft OptiGun GA03 ?complete, polarity negative, incl. pos. 1-9 1008 681

Shaft OptiGun GA03 ?complete, polarity positive, incl. pos. 1.1-9 1008 682

1 Cascade ?complete, negative polarity 1007 231

1.1 Cascade ?complete, positive polarity 1007 232

2 Shaft (without cascade) 1008 675

3 Sealing piece ?complete (incl. pos. 3-7) 1008 690

4 Cascade space gasket 1009 646

5 Gasket 1008 686

6 Axial gasket 1008 687

7 Grub screw ?M5x5 mm 258 908

8 Threaded bolt 1009 587

9 O-ring ??4x1.5 mm 264 466

10 Gun rear end ?complete (incl. pos. 10-13) 1008 701

11 Lock knob 382 833

12 Screw ?M3x3 mm 266 795

13 Screw-in nipple ?M7-?6 mm 1008 699

14 Rear end cover 1008 697

15 Countersunk head screw ?M4x6 mm 214 639


Category: PG-2A Automatic Gun replacement Parts


«
