Art Crack Texture Polyester Powder Coating

Art-texture polyester powder coating






polyester texture wrinkle powder coating



Hammer texture powder coating

The features of hammer texture powder coating:

Main composition

Mainly made of epoxy resin,polyester resin and curing agent, leveling agent, pigment, filler and other addictives. it has super chemical resistance and mechanical properties. It can be used in painting those metal products that have special requirement of corrosion resistance, electric insulativity and pliability. Directly outdoor using is not to be suggested.

Products series

• Available in standard curing and lower temperature curing

• Available in multi-colors, different gloss level such as high gloss ( above 90°), flat gloss( 70-80°), semi gloss ( 10-60°), matt( below 10°), particular color and gloss is made according to customers requirements.

• Available in various kinds of art textures, such as sandy, wrinkle, lanose grain, hammer tone, metallic effect etc.

Physical property

Specific gravity: 1.11.8g/cm³ (varied with different color and gloss)

Particle size: average 10~38um, proportion 10~84um > 90%, it can be adjusted if special requirement is put forward to us in advance.

Curing temperature

Standard type: 180^oC/15 minutes

Or 160^oC/20 minutes, 200^oC/10 minutes if customer require

Pre-treatment

The overall quality of the coating system is largely dependent on the type and quality of the pre-treatment. The recommended types of pre-treatment for the most frequently used substrates are:

Aluminium	Chromate conversion
Steel	Zinc phosphate
Zinc coated steel	Zinc phosphate or chromate conversion



Coating method

• Electrostatic spray gun

• Tribo gun

• Electrostatic fluidized bed

• Fluidized bed

Average coating rate

A.      Smooth Surface:
6-12/KG, film thickness 60μm (calculated according to 100 consuming of powder coating)

B.     Texture Surface:

5-7/KG,film thickness is about 80-120μm

Package

Carton packing with liner of double polyethylene bags, Net weight 20kg each.

Storage and shippment

The product must be stored in ventilated, dry and clean room with temperature below 25^oC, Keep it away from fire, heat,and direct sunlight. Outdoor stacking is prohibited. Avoid rains and exposure to sunshine during shipment. The period of validity is 6 month under above condition. Expired products can not be used unless re-testing result meets the utilization standards.

Health and safety

There are no hazardous ingredients contained. Wearing anti-dust mask and goggles to avoid inhalation of dust. Try best to avoid longtime contact with powder. The coating adhesive to the skin can be washed with soap.

Attention

This technical data is only for user reference,the concrete index is to measure under the terms of suring, in case of the problem can not be solved, please contact the technology department of our company.

Art Crack Texture Polyester Powder Coating







Available hybrid, pure polyester resin and other types of art pattern effect powder coatings were suitable for indoor or outdoor use. This product has a unique luxurious look decorative effect, can help to mask the substrate itself is flawed. Widely used in various high-grade metal products coating.

For metallic effect powder coatings, should note the following points: (1) Since the types of products containing a metallic pigment, using an electrostatic gun in construction should ensure that the system is well grounded, while setting a lower amount of powder electrostatic voltage and, prevent ignition phenomenon generated when spraying. (2) In order to improve and overcome decorative coating of metallic pigments easy to clean off, we recommend the use of transparent powder coatings for varnish
Second, the product series

Available in sand grain, hammer, waterlines, marbling, tortoises, and many other effects metallic look of products.

According to the user needs to provide a variety of shiny products. (We do not recommend using the measured gloss coating gloss art-type)
Third, the physical properties of the powder

Specific gravity 1.2 - 1.8 (because of the color and gloss vary)

Particle size distribution: 100% smaller than 100 microns (depending on the specific indicators art effects, according to the special requirements of painting adjusted)

Mobility :120-140

Aluminium

Chromate conversion

Steel

Zinc phosphate

Zinc coated steel

Zinc phosphate or chromate conversion
