Electrostatic Polyester Powder Coating

Quantity:
Delivery Date: 2-10days Brand Name: colo Powder painting: Polyester material: polyester resins color: according to RAL gloss: according to request sample: can supply for testing quality packing: 25kgs/box used: outoor type suitable: metal product type: themosetting Storage: Store below 35 ℃, ventilated, dry, clean indoor


Polyester/Primid powder coating

Pure Polyester Powder Coating
electrostatic Polyester Powder Coating

electrostatic Polyester Powder Coating

Advantages:
   1. Excellent protection against corrosion
   2. Good resistance to weathering
   3. Without heavy metal
   4. No color limit
   5. NO VOC
   6. Environment friendly, with or without TGIC is possible
   7. Suitable for indoor and outdoor items

It is ideal coating and decoration of outdoor metal (steel or aluminum) items such as:
   1. Architectural materials such as aluminum, galvanized steel…,
   2. Road sign/pole,
   3. Automobile, bycicle
   4. Outdoor home appliance such as garden tools, railing,
   5. Appliance, such as air conditioner
   6. Outdoor furniture,
   7. Outdoor light-fixture
   8. Agricultural equipment,
   9. Playground equipment^

PHYSICAL PROPERTIES

  • Specific gravity : 1.2 ~ 1.8g/cm3 up to colors

  • Particle size distribution: 100% less than 100 microns (depending on the specific indicators art effects may be, according to the special requirements of painting adjusted)

  • Level of liquidity: 24 ~ 27 mm

CURING CONDITIONS

180 °C ~ 200 °C (work piece temperature), 10-15 minutes

COVERAGE

8-12 square meters / kg, thickness 60 microns (100% of the powder coating utilization rate)

STORAGE AND TRANSPORT

Stored in less than 30 °C, ventilated, dry, clean room, not near the fire source, heating, avoid direct sunlight, the product in the transport should be to prevent rain, sun, prolonged sun exposure. Storage products in line with the above conditions, since the date of production, effective storage period is 6 months. Over the storage period may be re-tested and the results were consistent with, can still be used.


Standard

Results

Impact

GB/T1732-1993

50cm

Cupping Test

GB/T9753-1988

6mm

Adhesion

GB/T9286-1998

0 Grade

Bend

GB/T6742-1986

3mm

Pencil Hardness

GB/T6739-199

1H-2H

Salt Spray

GB/T1771-1991

>500hrs

Humidity

GB/T1740-1989

>1000hrs

Remarks :

1. All above tests are carried out on 0.8mm steel panel with the film thickness of 60-80 microns.
2. Some types of color may have the reduced properties.


powder coating manufacturing process flow

electrostatic Polyester Powder Coating

colo powder coating workshop


electrostatic Polyester Powder Coating


Specifications

1. Various colors, finishes and shades.
2. Fast delivery due to we have 20 production lines now.
3. Accept small MOQ.

Product Range: Epoxy Powder Coatings, Epoxy-polyester Powder Coatings, Polyester Powder Coatings(TGIC/Primid), Polyurethane Powder Coatings, Metallic Powder Coatings, Functional Powder Coatings, Powder Coatings for MDF, etc.

Raw Materials: Polyester Resin, Flow Agent, Matting Agent, Benzoin, etc. For full specification and technical data sheet, please contact with Penny.
