Hammer Finish
Colors, gloss levels, metallic effects and textures in the photos may vary due to screen settings,products should always be tested before you place order.
Polyester Epoxy Gray Wrinkle Texture Powder Coating
The features of the wrinkle powder coatings:
Main composition
Mainly made of epoxy resin,polyester resin and curing agent, leveling agent, pigment, filler and other addictives. it has super chemical resistance and mechanical properties. It can be used in painting those metal products that have special requirement of corrosion resistance, electric insulativity and pliability. Directly outdoor using is not to be suggested.
Products series
Available in standard curing and lower temperature curing
Available in multi-colors, different gloss level such as high gloss ( above 90°), flat gloss( 70-80°), semi gloss ( 10-60°), matt( below 10°), particular color and gloss is made according to customers requirements.
Available in various kinds of art textures, such as sandy, wrinkle, lanose grain, hammer tone, metallic effect etc.
Physical property
Specific gravity: 1.11.8g/cm3 (varied with different color and gloss)
Particle size: average 10~38um, proportion 10~84um > 90%, it can be adjusted if special requirement is put forward to us in advance.
Curing temperature
Standard type: 180oC/15 minutes, 200oC/10 minutes
Pre-treatment
The overall quality of the coating system is largely dependent on the type and quality of the pre-treatment. The recommended types of pre-treatment for the most frequently used substrates are:
Aluminium | Chromate conversion |
Steel | Zinc phosphate |
Zinc coated steel | Zinc phosphate or chromate conversion |
Coating method
Electrostatic spray gun
Tribo gun
Electrostatic fluidized bed
Fluidized bed
Use
Home furniture and appliances
Instruments: Instrument,apparatus, medical equipment and optical instrument, etc.
Light Industry: Lighting lamps, steel furniture and aluminum products, etc.
Others: bookshelf, machinery and knitting machinery,racks.etc..
Powder Properties
Appearance: Homogeneous without any agglomerate
Specific Gravity: 1.2~1.7 (vary with the different type and color)
Flowing ability: 18~35mm
PSD: 100% smaller than100um
Curing
180-200°C 15-10 minutes
Coverage
8-11 square meters per kg with coat thickness 60 μm(calculated as the 100% usage rate).
Packing
Carton packaging, with polyethylene chloride bag, the net weight is 20 kg.
